Grundfos Scala2 3-45 Booster Pump

The Grundfos SCALA2 is a fully integrated, self-priming, compact waterworks for pressure boosting in domestic applications. SCALA2 incorporates integrated speed control enabling the keeping of the perfect pressure at the taps, meaning that the pump performance will increase with increasing demand.

Key features:

• Perfect water pressure: Intelligent pump control adjusts operation automatically
• Low noise: As quiet as a modern dishwasher (47 dB(A) in typical use)
• Easy selection: One variant for all domestic boosting needs
• Easy installation: Compact, all-in-one solution, plug-and-pump
• Easy to operate: User-friendly control panel
• Reliable operation: Dry-running protection, anti-cycling
• Long lifetime: Quality-tested to perfection, maintenance-free

The SCALA2 can be installed in three easy steps:

• Connect the pipes.
• Prime the pump.
• Plug the pump into the power outlet and the pump will start.

Please Note - This pump cannot be fitted directly to the water mains. A minimum of 1" suction pipe is required.

As it is self-priming, the SCALA2 is able to pump water from a level below the pump. Provided it is filled with water, the pump is able to lift water from a depth of 8 m in less than 5 minutes. This facilitates easy installation and start-up of the pump and provides more reliable water supply in installations where there is a risk of dry running and leakages in suction hose or pipes.

If exposed to dry running, water shortage or excessive temperature, blocked pump, for example in case of seizure or overload, the pump will stop automatically, thus preventing a motor burnout. Thanks to its hydraulic design, permanent magnet motor and water cooling, the pump is extremely low-noise, 47 dB(A) in typical use, which makes it suitable for indoor as well as outdoor use. Max. Noise level at full load are 53 dB(A)

SCALA2 require no maintainance, but it is recommended to keep the pump clean, check the non-return valves and keep the ventilation holes free of dust.

PolyTank 70 Gallon Coffin Tank

The Polytank 70 Gallon Coffin Tank (model 64-24-19) is a rectangular cold water storage tank designed for loft installations. It has a capacity of 318 liters (70 gallons) and dimensions of 1650mm (64 inches) in length, 610mm (24 inches) in width, and 500mm (19 inches) in height.

This tank is WRAS approved and kitemarked to BS4213:2004, ensuring compliance with UK water regulations.

Kit Includes:

• 1 x Coffin Tank
• 1 x Tank Jacket
• 1 x Screened Warning Pipe Elbow
• 1 x Vent Pipe Sleeve
• 1 x Screened Breather
• 1 x Dip Tube
• 1 x Ballvalve Backplate
• 1 x 1/2" Part 2 Ballvalve and Float
• 1 x 22mm Compression Tank Connector
• 1 x 15mm Chrome Bent Service Valve

Ideal Heating Pro 210L Indirect Unvented Cylinder

The Ideal Pro 210 L Indirect Unvented Cylinder is a type of hot water storage tank designed for use in homes or businesses that require a reliable and efficient hot water supply. Here's a breakdown of its features and specifications:

Key Features:

• Indirect Heating: The "indirect" part means that the cylinder heats water via a separate heat source, such as a boiler, instead of using direct electrical heating elements. The boiler heats water, which is then circulated through a coil or plate heat exchanger inside the cylinder to heat the stored water.
• Unvented: Being "unvented" means that the cylinder is pressurized. It does not rely on gravity or a cold water tank in the loft. The system works at mains pressure, delivering strong water flow to taps and showers.
• Size and Capacity (210L): This cylinder has a storage capacity of 210 liters, making it suitable for medium to large homes or businesses. It can provide hot water to multiple outlets simultaneously without a loss in pressure.
• Efficiency: The Ideal Pro Indirect Unvented Cylinder is designed with thermal insulation to minimize heat loss, ensuring efficient energy use and reducing heating costs.
• Durability: These cylinders are typically made with high-quality materials, ensuring long-lasting performance with proper maintenance.
• Safety Features: It often includes safety mechanisms like pressure relief valves, which are important for maintaining the safe operation of the unvented system.

Benefits:

• Better Water Pressure: Since the system operates on mains pressure, you can enjoy strong water pressure from taps and showers.
• Energy Efficiency: Indirect cylinders are energy efficient since they use a boiler to heat the water, which can be more cost-effective than electrical heating.
• More Hot Water: The 210-liter capacity means there’s more hot water available for simultaneous use.
• No Need for a Cold Water Tank: As it’s unvented, there’s no need for an additional cold water storage tank in the attic or loft, which can save space.

Ideal For:

• Homes with multiple bathrooms or high water demand.
• Properties with an existing central heating system, particularly a boiler.
• Those who want an efficient, pressurized hot water system without the need for an additional cold water tank.

The Ideal Pro 210 L Indirect Unvented Cylinder is a solid choice for those looking for a high-performance hot water system that delivers ample hot water with strong pressure, while also being energy-efficient and reliable.

Components supplied with Ideal Pro:

• Cold water inlet PRV combination valve/expansion relief
• Pressure and temperature relief valve
• Control thermostat
• Energy cut-out thermostt
• Energy cut-out motorised valve (indirects only)
• Tundish
• 1x 3kW Immersion heater including control and cut out thermostats
• Expansion vessel complete with mounting bracket
